Double hopper secondary packaging machine for PP woven master bag

Double hopper secondary packaging machine for PP woven master bag

The epidemic witnessed explosive growth in the demand for packaging automation. More and more customers turn to the automatic secondary packaging machine in order to increase the packaging capacity for retail sales, better control the packing process and improve the product quality by reducing the risk of contamination. The double hopper secondary packaging machine is perfect designed for the rapidly increased retail demands, it allow the primary VFFS bagging machine work at its top operational efficiencies by  interlocking with secondary packaging machine. The fully automatic secondary packaging machine automatically fill primary bags into the open mouth master bag in a certain order requested by customer. Widely applied for packing rice, sugar, seeds, pet food, detergent powder etc.

Products Details


APPLICATION:

Automatically pack small bag product into larger PP woven master bag, mainly involved in detergent powder, rice, sugar, wheat flour industry.


The complete system include:

1. Double layer climbing conveyor

2. Accelerating&Counting conveyor

3. Bag flap device and shaping hopper

4. Supporting platform

5. Double hopper secondary packing machine

6. Sewing machine& Sewing conveyor


Options

Check weigher

Metal detector

Robotic palletizing system



Features&Application :

1. To pack pouches of grains and powders into pre-formed bagsaccurate primary bag counting, beautiful master bag shape.

2. PP master bag replace carton box, save cost.

3. To overcomes manual and disorderly packaging.

4. 1 double-hopper secondary packaging machine can be interlocked with 4 intermittent vertical packaging machines or 2 continuous vertical packaging machines, which can meet the requirements of 7x24 continuous production and improve production efficiency.

5. It can be integrated with robot palletizing system to realize unmanned, automatic and intelligent production process.



Technical data:



Machine model

ZYEDSP2AA

Application of primary bag

0.25-10kg (customized hopper according to product range)

Max.infeed speed of primary bag

120-150bags/min

Packaging speed of master bag

4-8 bagsPP woven bag

Master bag size range

L585-950*W350-450*Gusset70-150

Master bag material

Open Mouth PP woven bag

Power supply

AC380V±5%50HZ

Max Power consumption

12KW

Air pressure

≥6kgf/c

Air consumption

1m³/min

Noise

≤80 dB

Machine material

Painted steel frame+Contact part SS304

Machine weight

7000kg


A free consultation

If you have questions or suggestions,please leave us a message,we will reply you will reply you in 24 hours
